General Specifications
Regulatory File Insert Official Number 1124247 in the Vessel Number box and click “search”
Drawing
Name | Majestic |
Style | Yacht |
Builder | Skipperliner Industries, Inc. |
Hull | Displacement |
USCG Certified | Yes |
USCG Dry Dock | In Process |
USCG Official Number | 1124247 |
Passenger Capacity | 129 |
Gross Tonnage | 76 |
Net Tonnage | 51 |
Speed (approx.) | Cruising: 7 knots @ 1,400 RPMMaximum: 9 knots @ 2,200 RPM |
Built | 2002 |
LOA | 91′ |
LWL | 82.2′ |
Beam | 20′ |
Hull Depth | 6′ |
Freeboard | 3.1′ |
Draft | Water 4′ 3″ Air Draft: 30′ |
Route Certification | Lakes, Bays and Sounds |
Hull Material | Steel |
Deckhouse Material | Steel |
Tank Capacities | Fuel: 1,000 gallonsWaste: 525 GallonsPotable Water: 425 Gallons |
Accommodations and Layout
The vessel is arranged with entry doors off the bow and stern. The main deck is arranged with dining throughout a beverage bar forward of amidships on port, the galley and two heads fully aft. The 01 deck allows for dining, beverage bar and the wheelhouse. Two companionways provide access between the main and 01 decks, one on port foreword; the second is aft on starboard. The fore deck and 01 decks aft offer open-air seating. This sleek styled vessel is well suited for sightseeing and dining cruise operations.
Wheelhouse
- Control station with VDO engine instrumentation (i.e., tachometer, engine oil pressure, ammeters, hour meters)
- Bilge alarm system
- Mathers Micro Commander (MMC) electronic dual clutch and throttle controls (propulsion and bow thruster)
- Rule bilge alarms
- Fog bell
- Large dual trumpet horn
- Remote controlled searchlight
- AutoNav rudder indicator
- Three windshield wipers
- Two ICOM model IC-M412 VHF/FM marine radios with antennas
- Raymarine model SL-70C radar with chart plotting
- Garmin model 185 GPS Sounder
- Ritchie Powerdamp compass
- Phone-Com by Newmar intercom system (wheelhouse/bar/galley/engine room)
- Defrost system (220 VAC)
- Yamaha model CDC-585 compact disc changer, Yamaha model KXW3214 cassette player, Rolls quartz synthesizer tuner, Elan Series Fan 2 with Bose speakers
- Weldex video camera with monitor
- Todd helm seat
Salons (Main & 01 Deck)
- 10 laminated tables (42” x 30”) – main deck
- 62 chairs (stacking) – main deck
- 15 laminated tables (42” x 30”) – 01 deck
- 66 chairs (stacking) – 01 deck
- 1 cocktail tables (60” diameter)
- 1 table (36” x 36”)
- 2 tables (72” x 30”)
Galley
- Laminated counter
- Two Wittco cook and hold ovens
- Two Moffat TurboFan 31 convection oven
- Amana microwave ovens
- CMA model L- IX dishwasher
- Mortin two burner cook top
- Silver King under counter freezer
- Silver King double door under counter refrigerator
- Ascend undercounter freezer
- True model DWT 48 refrigerator
- One stainless steel three partition sink
- One stainless steel single partition sink
- Bunn CW series coffe machine
- Chaffing dishes, pots, pans, etc.
- China, silverware & glassware
Beverage Bar (Main Deck)
- Laminated top
- Stainless steel sink
- Stainless steel three partition sink with ice bin
- True two keg cooler
- One True under counter cooler
- Stainless steel speed rail
- Sharp model XE-A22S cash register
Beverage Bar (01 Deck)
- Laminated top
- Stainless steel sink
- True four keg cooler
- Stainless steel three partition sink with ice bin
- Stainless steel speed rail
- Sharp model A42S cash register
- Service window – aft deck
Electrical
- One ship service 70.0 kW Marathon generator powered by a John Deere 4.5 liter marine diesel with fuel filter, seawater strainer and seacock (engine hours: 17,284 in April 2014)
- Ship to shore power switch
- 100 AMP 120/ 240 VAC shore power service
- 50’ 100 AMP/ 240 VAC power cord
- 115 VAC exterior and interior perimeter lighting
- 120 VAC/12 VDC lighting
- 120 VAC duplex outlets
- Five 12 VDC 8D enclosed heavy duty batteries
- Perko battery isolation switch
- Charles automatic 60 amp battery charger
- C-Charger 5000 series automatic 40 am battery charger – wheelhouse
- Cruisair 23 ton water cooled reverse cycle heat pump system with SMX II controls
- Two air cooled roof mount air conditioners – wheelhouse
- 24 VDC manifold bilge system
- Internationally approved navigation lights (i.e., port light, starboard light, stern light, masthead light, anchor light)
Hull, Superstructure and Decks
- 3/16” steel plate hull
- Ten gauge steel plate deckhouse
- Insulated deckhouses
- Five watertight compartments formed by four transverse bulkheads
- 6” split pipe rub rail
- Mahogany benches main deck forward
- Boarding gates: two forward and two aft
- Wooster stair treads
- Stainless steel thresholds
- Nine 15” kevels
- Deck fittings:
Electrical: starboard
Waste: starboard
Water: starboard
Fuel: starboard
Mechanical Equipment and Engine Details
- Two 6 cylinder turbo charged after cooled 300 HP Caterpillar model 3126 TA marine diesel engines, fuel filters, seawater strainers with seacocks (engine hours: 832 port, and 899 starboard in June 2014)
- ZF 2.5:1 marine gears
- Engine room insulation
- Two 29” four blade bronze dynaquad propellers
- 2” stainless steel shafts
- Cofferdam and 24 VDC pump for each shaft log
- ZF IRM 301A2 2.476:1 reduction gears
- Two 50 gallon hot water heaters
- 14” bow thruster powered by a Yanmar 22 hp @ 3,800 RPM diesel engine (engine hours 2,906 in June 2014)
- 24 VDC oil drain system (propulsion and generator engines
- Water system with accumulator tank
- Craftsman 5.5 hp air compressor
Heads
The vessel is equipped with two heads each contains the following:
- Head
- One urinal in the Men’s head
- One sink and faucet
- Toilet paper dispenser
- Paper towel dispenser
Safety Equipment
- 155 type I adult size personal flotation devices (stowed in deck boxes)
- 16 type I child size personal flotation devices (stowed in deck boxes)
- EPIRB
- Three 30” life rings one with line
- Five self actuated rescue lights
- Five B-II and One B-I 10 lb. dry chemical fire extinguisher
- Pyrotechnic distress signals
- Two fire stations including: two 1 1/2” UL approved rubber lined hoses with brass or bronze fittings, two brass or bronze nozzles, two brass or bronze hose bibs. The bilge pump system operates the fire system also
- Fire axe
- Bruce anchor
- Man overboard recovery ladder
Finish
- Exterior coating: Coating
- Exterior decks: Non skid
- Interior decks:
Salon: Carpeting
Heads: Ceramic
Galley: Altro
Bar: Ceramic
Wheelhouse: Carpeting - Headliner: Gage
- Interior Bulkheads:
Salon: Wood panel (cherry style)/carpet
Heads: Coated
Galley: Panel
Remarks
The MAJESTIC is in fair good condition. The yacht offers a sleek style and wonderful viewing for passengers. Two spare Silver King model SKR7F under counter refrigerators
Exclusions
N/A
