General Specifications
Insert Official Number 1119965 in the Vessel Number box and click “search”
| Name | Sachem |
| Style | Navy Launch |
| Builder | Willard |
| Architect | |
| Hull | Displacement |
| USCG Certified | Yes |
| USCG Dry Dock | April 2024 |
| Passenger Capacity | 28 |
| Gross Tonnage | 22 |
| Net Tonnage | 18 |
| Speed (approx.) | Maximum: 10 knots @ 2,200 RPM |
| Built | 1992 |
| LOA | 32.5′ |
| LWL | |
| Beam | 12′ |
| Hull Depth | 7′ |
| Freeboard | |
| Draft | Water 3′ |
| Displacement | |
| U.S.C.G. Official Number | 1119965 |
| Route Certification | Lakes, Bays and Sounds |
| Hull Material | FRP |
| Deckhouse Material | |
| Tank Capacities | Fuel: 50 gallons |
HELM STATION
- Control station with engine instrumentation (i.e., tachometer, engine oil pressure, ammeters, hour meters)
- Hydraulic steering
- VHF/FM marine radio
- Magnetic compass
ELECTRICAL SYSTEM
- Battery isolation switches
- 12 VDC bilge blowers
- Internationally approved navigation lights (i.e., port light, starboard light, stern light, masthead light, anchor light)
MECHANICAL EQUIPMENT AND ENGINE DETAILS
- 150 hp 6-cylinder Cummins model 6BT water cooled marine diesel engine.
- 1.5” diameter propeller shaft
- Three blade bronze propeller.
- 2:1 reduction gear
SAFETY EQUIPMENT
- 32 type II adult size personal flotation devices
- 24type II child size personal flotation devices
- One Jim Buoy 30” life ring with lines
- One 10 B:C and one 2-A fire extinguishers
- First aid kit
- An anchor
REMARKS
THE SACHEM is in good condition.
DISCLAIMER
Pinnacle Marine Corporation offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct their agents, or their surveyor(s), to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
