Osprey

General Specifications

Insert Official Number 1185331 in the Vessel Number box and click “search”

NameOsprey
StyleFerry – Deadrise Express
ArchitectDavid Mason
BuilderChesapeake Boats, Inc.
HullDisplacement
USCG CertifiedYes
USCG Dry DockAugust 2027
Passenger Capacity44 (22 Limited Coastwise)
Gross Tonnage22
Net Tonnage19
Speed17 knots @ 1,600 RPM
26 knots maximum
Built2006
LOA56′
LWL52′
Beam17′
Hull Depth4′
DraftWater 4.5′ Air Draft: 15′
Displacement25,000 lbs.
U.S.C.G. Official Number1185331
Route CertificationLakes, Bays and Sounds plus Limited Coastwise
Hull MaterialFRP over wood
Tank CapacitiesFuel: 800 gallons – stainless
Waste: Lectra San
Water: 55 gallons – plastic

ACCOMMODATIONS AND LAYOUT

The vessel is arranged with berths forward then galley to starboard and head port with a salon including a C shaped settee and L shaped seating. The aft deck is set with wooden benches and chairs.

WHEELHOUSE

  • Kobelt levers with Morse cable throttle and clutch control system
  • Teleflex SeaStar hydraulic steering system
  • Cockpit helm
  • Three AFI windshield wipers
  • Ritchie 2.5” compass
  • Garmin model 200 VHF/FM marine radio with antenna
  • Standard Horizon model HX210 handheld VHF/FM marine radio
  • SIMRAD model GL-12 12” color display global positioning system (GPS)
  • JRC model JMA-2343 Raster Scan radar
  • SIMRAD model AP254 autopilot
  • Furuno model FCV-582L depth sounder
  • Furuno model FA-150 AIS class A transponder
  • Jensen model MCD5112 stereo with six Jensen speakers
  • Starmate Sirius satellite radio
  • Samsung 32” television monitor
  • Cadelpoint Wi-Fi system

ELECTRICAL SYSTEM

  • Onan model e-QD 10 kW generator powered by a Cummins marine diesel engine (NEW 2019)
  • Hours: 6,781 July 2025
  • Three Blue Sea battery switches
  • Perko battery switch
  • Pro Mariner Pro Sport 24 VDC battery charger
  • Sterling Pro Charger 12 VDC battery charger
  • Internationally approved navigation lights (i.e., port light, starboard light, stern light, masthead light, anchor light)
  • Two 30-amp shore power outlets
  • Two 50 shore cords
  • 22 Fishing rod holders

HULL, SUPERSTRUCTURE AND DECKS

  • Fiberglass Reinforced Plastic (FRP) hull
  • Four watertight bulkhead with three compartments
  • Two wood picnic tables

MECHANICAL EQUIPMENT AND ENGINE DETAILS

  • Twin 4 cycle, turbo charged and aftercooled in line 6-cylinder Caterpillar model C18 873 hp @ 22000 (D rating) tier 0, marine diesel engine, fuel filter, seawater strainer with seacocks. Heat exchangers are ready for service
  • Serial numbers CKH00633/CHK01335
  • Hours: 6,721/6,738 July 2025
  • Caterpillar vibration dampening type engine mounts
  • Caterpillar synchronizer and slow mode control panel
  • Block heaters
  • ZF Marine model 550A 1.525:1 reduction gears
  • 2.5” stainless steel propeller shafts
  • Conquest Hi Torque four blade 30” x 34” propellers
  • Super Power 225 24 VDC 12” thruster
  • CruisAir 32,000 BTU water cooled reverse cycle heat pump system
  • Heatercraft heater
  • West Marine dehumidifier
  • 10-gallon water heater
  • Jasco oil transfer system
  • Lenco trim tab system with stainless steel tabs and dual actuator

GALLEY/SALON

  • Whirlpool refrigerator
  • Sunbeam microwave oven
  • Setee to starboard and port

CREW QUARTERS

  • V berth

HEAD

  • Jabsco electric head
  • Sink and faucet
  • Lectra San waste treatment system

SAFETY EQUIPMENT

  • 46 type I adult size personal flotation devices
  • 5 type I child size personal flotation devices
  • One life ring with line
  • Two 12-person life float
  • ACR model RLB-36EPIRB
  • One 10-B:C, two 2-A and one 40-B:C fire extinguishers.
  • Easy Puller 24 VDC horizontal anchor windless
  • West Marine Trad-40 fluke type anchor

EXCLUSIONS

  • N/A

REMARKS

  • The P/V OSPREY is in very good condition.  She has been very well maintained. The USCG COI will be made current prior to Closing, except operational type requirements such as drug testing plan enrollment, man overboard drill, and life float  inspection.

Pinnacle Marine Corporation offers the details of this vessel in good faith but does not and cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct their agents, or their surveyor(s), to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
